TECHNICAL SPECIFICATION:
Model No |
HIS-HBSD-01 |
Type |
Micro - Controller based |
Principle |
Human Body static dissipater provides complete solution, by measuring the Resistance of human body and providing conductive path for static charge dissipation to earth |
Display Range |
0 to 1 MEGA OHM |
Relay O/p |
Two C/o (Potential Free Contacts) |
Control action |
Relay will get energized when the body resistance is below 1 mega ohm the device display 'PASS When the Resistance above 1 mega ohm, the device displays 'open relay will get de-energized |
Power supply |
110 V / 230 V AC, 50 H2 |
Protection |
Enternal Fuses |
Execution |
Explosion - Proof Ex 'd |
Display Size |
16 x 2 Jumbo LCD Display |
Dimension | 250 x 250 x 140 mm |
IP Protection : |
IP65 |
Mounting |
Wall Mounting SS Plate |
Handle |
Test Handle & Reference Ground Handle / power on/off Switch : 16 AMP |
Apperatus Standard |
Ex 'd - 15/IEC 60079-1:2014 |
Temperature Class : |
T6 (85 deg. C) |
Area Classification |
Zone 182 |
Gas Groups |
IIA / IIB, IIC & T6 |
Cable Enteries |
One bottom of Enclosure 3/4" ET |
